World's only "DUAL SPRING MECHANISM"
Stronger Contact Pressure, Higher Vibration/ Impact Durability

uchiya logo

HOME  TOP page


TOP ‰οŽΠξ•ρ seihin kankyou kenkyu saiyou otoiawse
 Specifications  Dimensions  Applications
Operating
Temp
60`100‹C
i5C stepj

  Lithium-ion Battery Pack
Tolerance }5‹C,}7‹C,}10‹C,     NiMH Battery Pack
Resetting
Temp
46C or higher     NiCd Battery Pack
Maximum non-trip current     DC Small Motor

21A
(Operating temp 80C Ambient 25C)
12 A
(Operating temp 80Cƒ’T=15K)
ƒ’T=Operating temp-Ambient temp




Maximum
cut-out current
120A 12V DC

 Safety Approval @ *Contact us for approved conditions in detail.
Model
Agency
Standard
Category
Electrical
Ratings
Max
Temp
File No. .
BPF
UL
UL873
Regulating
15A/18V DC
(resistive) 6000‰ρ
100C
E50124
c-UL
CSA C22.2 No.24
Appliance Control
15A/18V DC
(resistive) 6000‰ρ
100C
E50124
EN(VDE)
EN60730-2-9
Thermal Cut-out
15A/18V DC
(resistive) 6000‰ρ
100C
892100-
4510-0034
CQC
GB14536.10
Thermostat
(Non-fused bimetal type)
15A/18V DC
(resistive)
100C
CQC11002059931
CQC11002059933

>>Tripping Time vs Current (at 25C)
>>Operating Temp Drop due to Current
